Fostex 6301DT
- Ordered before 15:00, shipped the same day, provided products are in stock.
- Have you seen a better price? Let us know and we'll try to match it. To Price-Match Form.
- Tax free for customers outside the Netherlands (with a valid VAT number).
- Do you have a question about this product? Chat with us and we'll tell you all about it!
- The compact design common to all series allows for space-saving
installation.
- Cone-type full-range speakers are used to achieve stable sound.
- Rugged die-cast aluminum enclosure is used.
- Flat design with minimal protrusion of switches and knobs to prevent
damage even in the event of a fall.
- Switching power supply circuitry compatible with 100 VAC to 240 VAC
power supplies.
- Either or both of the 2-channel digital signals extracted from the
Dante® network signal can be output.
- Incorporates Dante® Ultimo chip. Supported sampling frequencies:
44.1/48/88.2/96 kHz
- An optional wall-mounting angle (EB-6301) allows for angle adjustment
and wall mounting.
Specifications
Main Specifications
| Speaker section | |
|---|---|
| Enclosure type | Closed type (Material: Aluminum die-cast) |
| Unit | Cone type 10cm full range unit x 1 |
| Frequency response | 70Hz to 15kHz |
| Sound Pressure Level | 85dB/W(1m) |
| Maximum Sound Pressure Level | 98 dB |
| Amplifier section | |
| Rated output | 20W |
| Input connector |
Analog unbalanced/Φ6.3 mm (1/4″) TS phone, Dante/RJ45 (CAT5e or better) |
| T.H.D. | 0.05 % (at 1 kHz 1 W output) |
| Residual noise | -65 dBV |
| general | |
| External Dimensions |
120(W)×189(H)×120(D)mm *including maximum projection |
| Weight | Approx. 2.3 kg |
| Power requirement | AC 100 V to 240 V, 50/60 Hz |
| Power consumption |
10 W *This product does not have an auto-standby function. |
| Accessories | Power cord (approx. 2 m) × 1 |
