Sound Devices Astral Mini Plus
Sound Devices Astral Mini Plus
- Ordered before 15:00, shipped the same day, provided products are in stock.
- Have you seen a better price? Let us know and we'll try to match it. To Price-Match Form.
- Tax free for customers outside the Netherlands (with a valid VAT number).
- Do you have a question about this product? Chat with us and we'll tell you all about it!
Delivering a discreet profile and long-duration power options, the Astral Mini Plus features an expansive 169–1525 MHz SpectraBand RF tuning range, IP67 waterproof protection, integrated charging, and a sunlight-readable ePaper display. A streamlined interface and robust remote-control capabilities ensure fast, intuitive operation in the field.
Astral Mini Plus Tx Features:
- IP67 waterproof and sweat-proof construction
- 8+ hours battery life using one or two XL-B14500 rechargeable cells
- Built-in USB-C charging for simple power management
- Full 169–1525 MHz SpectraBand tuning for global operation
- NexLink long-range remote control built in
- Sunlight-readable ePaper display visible even with no battery installed
- GainForward Architecture — no transmitter gain to set
- 32-bit float, 48 kHz recording with 64 GB storage (approx. 80 hours)
- 2- and 3-wire lav compatibility
- Integrated rotatable belt clip (0°, 90°, 180°, 270°)
- Bluetooth remote control with Astral Remote app
- Internal timecode generator with NexLink jamming support
Built for the Elements
With IP67 water protection, a rugged housing, and a rounded ergonomic shape, Astral Mini Plus withstands sweat, movement, weather, and the harsh conditions found in live and location production.
All-Day Power
Astral Mini Plus supports one or two XL-B14500 rechargeable cells for extended runtime. The built-in USB-C charging port simplifies battery management in fast-paced production workflows.
Wide-Open RF Freedom
The full SpectraBand 169–1525 MHz tuning range enables legal and reliable operation across the globe without requiring hardware changes — ideal for touring, broadcast, and multi-venue work.
Fast, Practical Workflow
- Tap-to-pair app setup with integrated RFID
- Sunlight-readable ePaper display remains visible even when unpowered
- Vibrate-to-identify function for quick transmitter location
Big, Clean Sound - Minus the Hassle
Astral Mini Plus features Sound Devices' GainForward Architecture keeping audio clean, consistent, and unclipped across the full 10 Hz - 20 kHz bandwidth by eliminating transmitter gain staging. Levels are set entirely at the mixer for simplified setup and reliable performance.
Astral Mini Plus Technical Specs:
| Water Resistance | Waterproof, sweatproof, IP67 |
| Battery Duration | 8+ hrs @ 20 mW* |
| Battery Type | XL-14500 (x1 or x2) |
| 3-wire lav operation | Yes, 3-wire and 2-wire |
| Display | ePaper |
| Belt clip | Integrated |
| SpectraBand | 169 – 1525 MHz |
| VHF operation | Yes |
| Tap to connect app | Yes (incl. RFID tag) |
| Vibe-to-notify | Yes |
| Antenna connector | SSMA |
| Onboard Recording | 64 GB (approx. 80 hrs)* |
| RF power settings | 5, 10, 20 mW |
